ОСНОВНЫЕ ПАРАМЕТРЫ
| Clamping taper | 50 | ISO |
| Tool shank | 69871 | DIN |
| Max. spindle speed | 3 000 | rpm |
| Max. transmitted power | 25 | kW |
| Max. spindle speed torque | 1 200 | Nm |
| Speed transmission from machine spindle to milling head spindle | 1:1 | |
| Angle range of the rotary part | ±180 | deg |
| Hydraulic power supply to the front of the headstock | min. 8 | MPa |
| Total milling head weight (inclusive connecting flange) | ca. 250 | kg |
