Horizontal boring mills

WH10CNC|26.7.2022

■  TABLE TYPE HORIZINTAL BORING MILL

■  PRODUCER: TOS VARNSDORF

■  REPAIR YEAR: 2022

■  PRODUCTION YEAR: 1999

■  CONDITION: USED, VERY GOOD

■  WARRANTY: YES

■  IN STOCK AT THE SUPPLIER

Request

Specification

■  HEIDENHAIN TNC426 control system

■  Handwheel HR410

■  SIEMENS motors and drives



SCOPE OF REPAIR 2022

■  Cleaning, revision and reassembly of machine groups, commissioning and technical inspection

■  Complete machine geometry repair (geometric accuracy protocol on request)

■  Replacing of bushing and wipers of spindle guiding support

■  Grinding of guideways of the stand and addition of hardened steel plates on the angular surface of the Y axis (counterway is coated with TURCITE)

■  Replacing of lighting

■  Replacing of bearings of headstock balancing guide rolls

■  Replacing of all guideay wipers

■  Repairing of guideway surface of support wedge and replacing of cover plate



Parameters

Workspindle diameter 100 mm
Clamping taper 50 ISO
Spindle speed range 2200 rpm
Transversal table travel (X) 1250 mm
Vertical headstock travel (Y) 1120 mm
Longitudinal table travel (Z) 940 mm
Spindle stroke (W) 630 mm
Table clamping surface 1000x1120 mm x mm
Table loading capacity 3000 kg
