WH10CNC|26.7.2022
■ TABLE TYPE HORIZINTAL BORING MILL
■ PRODUCER: TOS VARNSDORF
■ REPAIR YEAR: 2022
■ PRODUCTION YEAR: 1999
■ CONDITION: USED, VERY GOOD
■ WARRANTY: YES
■ IN STOCK
Specification
■ HEIDENHAIN TNC426 control system
■ Handwheel HR410
■ SIEMENS motors and drives
SCOPE OF REPAIR 2022
■ Cleaning, revision and reassembly of machine groups, commissioning and technical inspection
■ Complete machine geometry repair (geometric accuracy protocol on request)
■ Replacing of bushing and wipers of spindle guiding support
■ Grinding of guideways of the stand and addition of hardened steel plates on the angular surface of the Y axis (counterway is coated with TURCITE)
■ Replacing of lighting
■ Replacing of bearings of headstock balancing guide rolls
■ Replacing of all guideay wipers
■ Repairing of guideway surface of support wedge and replacing of cover plate
ПАРАМЕТРЫ
| Workspindle diameter | 100 | mm |
| Clamping taper | 50 | ISO |
| Spindle speed range | 2200 | rpm |
| Transversal table travel (X) | 1250 | mm |
| Vertical headstock travel (Y) | 1120 | mm |
| Longitudinal table travel (Z) | 940 | mm |
| Spindle stroke (W) | 630 | mm |
| Table clamping surface | 1000x1120 | mm x mm |
| Table loading capacity | 3000 | kg |
