WHN13CNC, 2006
■ TABLE TYPE HORIZINTAL BORING MILL
■ PRODUCER: TOS VARNSDORF
■ PRODUCTION YEAR: 2006
■ CONDITION: USED, EXCELENT
■ WARRANTY: YES
■ ON STOCK AT THE SUPPLIER
Specification
■ HEIDENHAIN iTNC530 control system + handwheel
■ only 6000 hours spindle run
■ 50 pieces of tools ISO 50
■ operator platform
ПАРАМЕТРЫ
| Spindle diameter | 130 | mm |
| Spindle taper | 50 | ISO |
| Turning speeds | 10 - 3000 | rpm |
| Transversal table travel (X) | 3500 | mm |
| Vertical headstock travel (Y) | 2500 | mm |
| Longitudinal table travel (Z) | 1250 | mm |
| Spindle stroke (W) | 800 | mm |
| Table clamping surface | 1800 x 2200 | mm |
| Table loading capacity | 12000 | kg |
