Horizontal boring mills

WHN13CNC, 2013|3.3.2022

■  T-TYPE HORIZONTAL BORING MILL

■  PRODUCER: TOS VARNSDORF

■  PRODUCTION YEAR: 2013

■  CONDITION: USED, EXCELLENT

■  WARRANTY: YES

■  ON STOCK

Request

SPECIFICATION

■  HEIDENHAIN iTNC530 control system + handwheel

■  CNC table - full B axis controll

■  CHOV-20bar – cooling through spindle

■  additional headstock cooling Schimpke

■  including covered operator platform and safety fences

Parameters

Workspindle diameter 130 mm
Clamping taper 50 ISO
Spindle speed range 3000 rpm
Transversal table travel (X) 6000 mm
Vertical headstock travel (Y) 2500 mm
Longitudinal table travel (Z) 1600 mm
Spindle stroke (W) 800 mm
Table clamping surface 2500 x 1800 mm x mm
Table loading capacity 25000 kg
