WHN13CNC, 2013|3.3.2022
■ T-TYPE HORIZONTAL BORING MILL
■ PRODUCER: TOS VARNSDORF
■ PRODUCTION YEAR: 2013
■ CONDITION: USED, EXCELLENT
■ WARRANTY: YES
■ ON STOCK
SPECIFICATION
■ HEIDENHAIN iTNC530 control system + handwheel
■ CNC table - full B axis controll
■ CHOV-20bar – cooling through spindle
■ additional headstock cooling Schimpke
■ including covered operator platform and safety fences
ПАРАМЕТРЫ
| Workspindle diameter | 130 | mm |
| Clamping taper | 50 | ISO |
| Spindle speed range | 3000 | rpm |
| Transversal table travel (X) | 6000 | mm |
| Vertical headstock travel (Y) | 2500 | mm |
| Longitudinal table travel (Z) | 1600 | mm |
| Spindle stroke (W) | 800 | mm |
| Table clamping surface | 2500 x 1800 | mm x mm |
| Table loading capacity | 25000 | kg |
Галерея
