WHQ13.8CNC, 2004 | 7. 6. 2021
■ T-TYPE HORIZONTAL BORING MILL
■ PRODUCER: TOS VARNSDORF
■ PRODUCTION YEAR: 2004
■ CONDITION: USED, EXCELENT
■ WARRANTY: YES
■ ON STOCK AT THE SUPPLIER
Specification
■ HEIDENHAIN iTNC530 control system + handwheel
■ ATC60 automatic toolchanger
■ CHOV-20bar – tool cooling
■ Protective workpiece cover KVR
■ in the 2013 was the column-saddle after a weight fall expertly repaired by RETOS
ПАРАМЕТРЫ
| Spindle diameter | 130 | mm |
| Spindle taper | 50 | ISO |
| Turning speeds | 3000 | rpm |
| Transversal table travel (X) | 3500 | mm |
| Vertical headstock travel (Y) | 2500 | mm |
| Longitudinal table travel (Z) | 1250 | mm |
| Spindle stroke (W) | 800 | mm |
| Table clamping surface | 1800 x 2200 | mm x mm |
| Table loading capacity / with KVR | 8000 / 12000 | kg |
